WECGrid.db - Pre-loaded Database

Overview

A pre-loaded database is included with WEC-Grid to lower barriers to entry. It contains two WEC simulations (RM3 and LUPA) and corresponding grid simulations covering a 24-hour period. This allows users without MATLAB/WEC-Sim or PSS®E licenses to run examples immediately and compare results.

Grid Simulations

PSS®E: RTS-GMLC System

  • Flat Run (ID = 1)

    • Duration: 24 hours
    • Resolution: 5 min (288 steps)
    • Load curve: none

  • WEC Run (ID = 2)

    • Duration: 24 hours
    • Resolution: 5 min (288 steps)
    • Configuration: RM3 Farm with 10 devices at Bus 326
    • Load curve: none

WEC-Sim Runs

RM3

WEC-SIM RM3 Results
  • Simulation Details
    • ID: 1
    • Model: RM3
    • Simulation length: 24 hours (86,400 s)
    • Time step: 0.1 s
    • Spectrum type: PM (Pierson–Moskowitz)
    • Wave class: irregular
    • Wave height: 2.5 m
    • Wave period: 8.0 s
    • Wave seed: 42

LUPA

WEC-SIM LUPA Results
  • Simulation Details
    • ID: 2
    • Model: LUPA (14 meter diameter)
    • Simulation length: 24 hours (86,400 s)
    • Time step: 0.1 s
    • Spectrum type: PM (Pierson–Moskowitz)
    • Wave class: irregular
    • Wave height: 2.5 m
    • Wave period: 8.0 s
    • Wave seed: 63

Download WECGrid.db
